Rotary kiln

Rotary Kiln

Mainly used for magnetic roasting of lean iron ore, oxidation roasting of chromium, nickel iron ore
Rotary kiln

Product specification:Φ2.5×40m-Φ6.0×95m

Production capacity:168-10000t/h

Rotation speed:0.1–5 r/min

Applied materials: roasting cement clinker in the industries of metallurgy, refractory matter and chemical plant.

Overview

Rotary kiln is also known as lime rotary kiln. According to different processed materials, rotary kiln can be divided into cement kiln, metallurgy chemical kiln and lime kiln. It is mainly used for calcining cement clinker and can be classified into production of dry cement kiln and wet cement kiln .Rotary kiln is widely applied into building materials, metallurgy, chemical industry, environmental protection and many other production industries.

Rotary kiln

Features

1. Low energy consumption, energy saving.

2. Easy to maintain.

3. Reasonable price and long life expectancy.

Fote is a indirect fired rotary kiln supplier with high reputation. The product made in Fote is with high quality and reasonable price. We are always at your service. You can leave us a message to know more about the machine.

Parameter

Product
Specification
(m)
Kiln dimensions Motor
power
(kw)
Total
weight
(t)
note
Diameter
(m)
Length
(m)
Obliquity
(%)
Capacity
(t/d)
Rotation
speed
(r/min)
Φ2.5×40 2.5 40 3.5 180 0.44-2.44 55 149.61

-----

Φ2.5×50 2.5 50 3 200 0.62-1.86 55 187.37 -----
Φ2.5×54 2.5 54 3.5 280 0.48-1.45 55 196.29

outside

disassemble

kiln

Φ2.7×42 2.7 42 3.5 320 0.10-1.52 55 198.5 ------
Φ2.8×44 2.8 44 3.5 450 0.437-2.18 55 201.58

outside

disassemble

kiln

Φ3.0×45 3 45 3.5 500 0.5-2.47 75 210.94 ------
Φ3.0×48 3 48 3.5 700 0.6-3.48 100 237

outside

disassemble

klin

Φ3.0×60 3 60 3 800 0.3-2 100 310 ------
Φ3.2×50 3.5 50 4 1000 0.6-3 125 278

disassemble

klin

Φ3.3×52 3.3 52 3.5 1300 0.266-2.66 125 283

kiln with

preheater

precalcine

Φ3.5×54 3.5 54 3.5 1500 0.55-3.4 220 363

kiln with

prehrater

precalcine

Φ3.6×70 3.6 70 3.5 1800 0.25-1.25 125 419

Generating

klin for

usimg ofterheat

Φ4.0×56 4 56 4 2300 0.41-4.07 315 456

klin with

prehrater

precalcine

Φ4.0×60 4 60 3.5 2500 0.396-3.96 315 510

klin with

prehrater

precalcine

Φ4.2×60 4.2 60 4 2750 0.41-4.07 375 633

klin with

prehrater

precalcine

Φ4.3×60 4.3 60 3.5 3200 0.396-3.96 375 583

klin with

prehrater

precalcine

Φ4.5×66 4.5 66 3.5 4000 0.41-4.1 560 710.4

klin with

prehrater

precalcine

Φ4.7×74 4.7 74 4 4500 0.35-4 630 849

klin with

prehrater

precalcine

Φ4.8×74 4.8 74 4 5000 0.396-3.96 630 899

klin with

prehrater

precalcine

Φ5.0×74 5 74 4 6000 0.35-4 710 944

klin with

prehrater

precalcine

Φ5.6×87 5.6 87 4 8000 Max4.23 800 1265

klin with

prehrater

precalcine

Φ6.0×95 6 95 4 10000 Max5 950×2 1659

klin with

prehrater

precalcine
