Impact crusher

Impact Crusher

Effective control toward size and shape of aggregates
Impact crusher

Production capacity:30-800t/h

Feed opening:400×730-1260×2040mm

Feeding size:300-700mm

Applied Materials: Soft and medium hard minerals: limestone, feldspar, calcite, barite, talc, rare earth, clay, kaolin,etc.

andesite plaster stone limestone quartzite
More Material

Free download Product informationImpact Crusher(1.36M)

Overview

Impact crushers are also known as impact breakers or impact crushing machines. It can crusher the material whose side length is below 100-500mm and highest compressive strength can reach to 350Mpa. The advantages of impact crusher are that the crushing ratio is large and the materials after being crushed are all cube particles.

Impact Crusher Material Processing

The impact crusher is widely used to crusher materials in building materials, ore crushing, railway, highway, energy, transportation, energy, cement, mining, chemical and other industries.

Fote is a famous rock impact crushers supplier and also one of the well-known stone impact crusher manufacturers. You can get your ideal equipment here.

Impact crusher

Features

1. Simple structure, small size, light weight, large capacity, low production costs.

2. Large feeding mouth, high crushing chamber, high flexibility of material hardness.

Impact crusher

3. Crushing ratio can up to 40mm.

4. The gap between the impact plate and plate hammer can be easily adjusted, effective control of the particle size, particle shape is good.

5. Easy maintenance, economical and reliable.

Impact crusher

Parameter

Model Specification
(mm)
Feed
opening
(mm)
The Maximum
Feeding Size
(mm)
Capacity
(t/h)
Power
(kw)
Overall
dimension
(L×W×H)
(mm)
Total
weight
(t)
PF-1007 Φ1000×700 400×730 300 30-70 4P   37-45 2330×1660×2300 12
PF-1010 Φ1000×1050 400×1080 350 50-90 4P   45-55 2370×1700×2390 15
PF-1210 Φ1250×1050 400×1080 350 70-130 6P   110 2680×2160×2800 17.7
PF-1214 Φ1250×1400 400×1430 350 80-180 6P   132 2650×2460×2800 22.4
PF-1315 Φ1320×1500 860×1520 500 100-280 6P   200 3180×2720×2620 27
PF-1320 Φ1300×2000 993×2000 500 140-380 6P   250 3220×3100×2620 34
PF-1520 Φ1500×2000 830×2040 700 200-550 4P   315-400 3959×3564×3330 50.6
PF-1820 Φ1800×2000 1260×2040 800 400-800 4P   630-710 4400×3866×4009 83.21
