Vibrating feeder

Vibrating Feeder

Necessary part for screening and crushing lines
Vibrating feeder

Processing capacity:1-105t/h

Feeding size:125-250mm

Feed opening: 150×250-300×1300mm

Applied Materials: Pebbles, granite, basalt, iron ore, limestone, quartz stone, gangue, construction waste.

calcite gold ore limestone quartz stone
More Material

Overview

Vibrating feeder is also called vibratory feeder or ore vibrating feeder. And vibrating grizzly feeder is a important member of vibrating feeder. In the production process, vibrating feeder can feed the bulk or particle material into the material receiving device from the storage bin uniformly and constantly. Also it can make a coarse screening for the materials. The vibrating feeder is widely used in metallurgy, coal, mineral processing, building materials, chemicals, abrasives and other industries.



Fote is a famous vibration feeder supplier and has got high reputation in domestic and foreign market. We have high quality product and perfect. Welcome to have a visit. We’ll always at your service.



Vibrating feeder

Features

1. Simple structure, feeding uniform, continuous good performance, exciting force is adjustable.

2. Easy to operate.

Vibrating feeder

3. Low noise, low power consumption, regulation performance, no red material phenomenon.

4. Can adjust the feeding volume evenly.

Parameter

Model Max.
Feeding
Size
(mm)
Processing
Capacity
(t/h)
Motor
Power
(kw)
Obliquity
of material
trough
(°)
Trough
size
(mm)
Dimensions
(L×W×H)(mm)
GZD-650×2300 300 80-100 1.2×2 10-20 650×2300 2300×1360×780
GZD-750×2500 350 100-130 1.5×2 10-20 750×2500 2500×1460×780
GZD-850×3000 400 120-150 3×2 10-20 850×3000 3110×1800×1600
GZD-1000×3600 500 150-200 3.7×2 10-20 1000×3600 3850×1950×1630
GZD-1100×3600 580 240-300 3.7×2 10-20 1100×3600 3600×2050×1660
GZD-1300×3600 650 450-600 7.5×2 10-20 1300×3600 3900×2350×1750
GZD-1500×3600 1050 450-1000 7.5×2 10-20 1500×3600 3900×2000×1750
GZD-2000×3600 1200 550-1000 10×2 10-20 2000×3600 3600×2000×1750
GZD-2500×5000 1500 650-1500 18×2 10-20 2500×5000 5000×2500×1800
ZSW-380×95 500 100-180 11 0-10 3800×960 3920×1640×1320
ZSW-490×110 630 150-400 15 0-10 4900×1100 4980×1830×1320
ZSW-490×130 750 400-700 22 0-10 4900×1300 4980×2580×2083
ZSW-600×130 750 400-700 22 0-10 6000×1300 6082×2580×2083
ZSW-600×150 800 500-900 30 0-10 6000×1300 6086×2662×1912
ZSW-600×180 900 700-1300 45 0-10 6000×1500 6310×3262×2230
ZSW-600×200 1200 800-1500 55 0-10 6000×2000 6310×3462×2230
